Name: High-Speed 5W UV Laser Engraving Machine New Cabinet Laser Marking for Metal Wood Acrylic PVC Leather Glass Supports DXF PLT BMP
Brand: Wuhan Hgguanghe Technology Co., Ltd.
Availability: InStock

Home Products Cabinet laser marking machine

High-Speed 5W UV Laser Engraving Machine New Cabinet Laser Marking for Metal Wood Acrylic PVC Leather Glass Supports DXF PLT BMP

Product Details:

Place of Origin:	Hubei, China
Brand Name:	hgnova
Certification:	CE ISO

Contact Now

Detailed Product Description

Working Accuracy:	0.01mm	Graphic Format Supported:	AI, PLT, JPg, DXF, BMP, Dst, DXP
Laser Type:	Uv Laser	Condition:	New
Marking Depth:	0.01-0.5mm, 0.01-0.5mm	Marking Speed:	<7000mm/s, 0-7000mm/s
Cnc Or Not:	Yes	Cooling System:	Water Cooling
Weight (kg):	130	Key Selling Points:	Easy To Operate
Warranty:	1 Year	Mode Of Operation:	Pulsed
Configuration:	Bench-top	Feature:	Water-cooled
Product Name:	Desktop UV Laser Marking Machine	Application:	Acrylic MDF Plastic Fabric Wood
Machine Type:	Desktop UV Laser Marker	Laser Wavelength:	355nm
Working Area:	105105mm/130130mm/160*160mm	After-sales Service Provided:	24h Online Service
Cooling System:	Walter Cooling

Product Description

Specification

Model	GH-5UK
Laser Power	>5w@30kHz
Laser wavelength	355nm
Pulse Repetition Frequency	10k~150kHz
Scanning Speed	F=170mm, ≤7000 mm/s
Focus Lens	F=170MM standard /F=210MM optional / F=254MM optional
Marking Range	105MMx105MM /130MMx130MM optional / 160MMx160MM optional
Cooling Method	Water
Lift shaft	Manual lifting；500MM
Power Supply	2.0KW/AC220V/50 HZ ±5%

Wuhan HGGuanghe Technology Co., Ltd

Located in Wuhan’s East Lake High-Tech Development Zone (China (Hubei) Pilot Free Trade Zone), is a wholly-owned subsidiary of Wuhan Huagong Laser Engineering Co., Ltd., part of HGTECH (Stock Code: 000988), a leading listed national high-tech enterprise.

Backed by a leading enterprise in China's laser equipment manufacturing industry

Huagong Laser (HGTECH) specializes in high-power cutting systems, precision micro-processing solutions, and laser source exports. Awarded the National Science and Technology Progress Award, the company leads the high-end laser equipment market globally.
