Name: Hot Sale 30w Cabinet CO2 Laser Marking Machine Non Metal Co2 Laser Engraving Machine Laser Marker for Wood Leather Acrylic
Brand: Wuhan Hgguanghe Technology Co., Ltd.
Availability: InStock

Home Products CO2 laser marking machine

Hot Sale 30w Cabinet CO2 Laser Marking Machine Non Metal Co2 Laser Engraving Machine Laser Marker for Wood Leather Acrylic

Product Details:

Place of Origin:	Hubei, China

Contact Now

Detailed Product Description

Working Accuracy:	0.01mm	Graphic Format Supported:	AI, PLT, DXF, BMP, Dst
Laser Type:	CO2	Voltage:	220V 50HZ
Condition:	New	Marking Depth:	0.01-0.5mm
Marking Speed:	≤7000 MM/S, <7000mm/s	Cooling System:	Air Cooling
Weight (kg):	100	Key Selling Points:	High-accuracy
Warranty:	1 Year	Mode Of Operation:	Pulsed
Configuration:	Bench-top	Feature:	Air-cooled
Product Name:	Co2 Laser Makring Machine	Applicable Material:	Non-metal Materials
Machine Type:	Cabinet Laser Marker	Marking Material:	Wooden Plastic Fabric Glass Leather
Power Supply:	AC220V/50HZ	After-sales Service Provided:	24 Hours Online

Product Description

Specification

Product Model	GH-30C
Laser Center Wavelength	10.6 μm
Nominal Average Output Power	30 W
Pulse Repetition Frequency	0–25 kHz
Scanning Speed	F=150MM,≤7000 MM/S
Focus Lens	Standard: F=150 mm Optional: F=200 mm / F=250 mm
Marking Range	107×107 mm 140×140 mm (with optional lens) 175×175 mm (with optional lens)
Standard Line Width	0.1 mm (material-dependent, @F=150 mm)
Minimum Character Height	0.4 mm (@F=150 mm)
Cooling Method	Air Cooling
Industrial Control Computer (IPC)	Enterprise-grade IPC with LCD monitor
Lifting Mechanism	Manual lift, nominal stroke: 300 mm
System Power Supply	1 kW / AC 220 V / 50 Hz ±5% (Voltage stabilizer required beyond range)
Grounding Requirement	Class D (Grounding resistance ≤1000 Ω)
Ambient Temperature	5–40°C (Air conditioning required beyond range)
Ambient Humidity	Non-condensing
Oil Contamination Tolerance	Prohibited
Condensation Resistance	Prohibited
Compressed Gas (Not Included as Standard)	0.5–0.7 MPa, oil/moisture-free

Wuhan HGGuanghe Technology Co., Ltd

Located in Wuhan’s East Lake High-Tech Development Zone (China (Hubei) Pilot Free Trade Zone), is a wholly-owned subsidiary of Wuhan Huagong Laser Engineering Co., Ltd., part of HGTECH (Stock Code: 000988), a leading listed national high-tech enterprise.

Backed by a leading enterprise in China's laser equipment manufacturing industry

Huagong Laser (HGTECH) specializes in high-power cutting systems, precision micro-processing solutions, and laser source exports. Awarded the National Science and Technology Progress Award, the company leads the high-end laser equipment market globally.
