Name: Small Fiber Laser Engraving Machine 20W 30W 50W Portable Handheld Fiber Laser Marking Machine for Metal
Brand: Wuhan Hgguanghe Technology Co., Ltd.
Availability: InStock

Home Products Handheld laser marking machine

Small Fiber Laser Engraving Machine 20W 30W 50W Portable Handheld Fiber Laser Marking Machine for Metal

Product Details:

Place of Origin:	Hubei, China
Brand Name:	hgnova
Certification:	CE ISO

Contact Now

Detailed Product Description

Working Accuracy:	0.01mm	Graphic Format Supported:	DXF, BMP, JPEG, PLT, Hpgl
Laser Type:	Fiber Laser	Condition:	New
Marking Depth:	0.01-0.1mm	Marking Speed:	≤7000mm/s, 0-7000mm/s
Cnc Or Not:	NO	Cooling System:	Air Cooling
Control Software:	Linux	Weight (kg):	7
Key Selling Points:	Easy To Operate	Warranty:	1 Year
Mode Of Operation:	Pulsed	Configuration:	Hand-held
Feature:	Air-cooled	Product Name:	Mini Handheld Fiber Laser Marking Machine
Applicable Material:	Metal Aluminum Stainless Steel	Laser Wavelength:	1064mm
Machine Type:	Mini Portable Laser Marker	After-sales Service Provided:	24 Hours Online
Working Area:	110110mm/150150mm/175*175mm	Power Supply:	110V/220VAC

Product Description

Specification

Model	M-Box( without battery）
Output power	20W/30W/50W
Marking range	110x110mm standard / 150x150mm optional /175x175mm optional
Laser wavelength	1064nm
Marking speed	＜7000mm/s
operating system	Linux system
Marking line type	Dot matrix and vector integrated machine
Line width	0.03mm
Repeat positioning accuracy	0.01mm
Positioning method	Red light positioning. focusing
Number of character lines	Any line within the effective marking range
Printing speed	800 characters (depending on the material and printing content)
Barcode	CODE39、CODE128、CODE126、QR
power supply	110V/220VAC
Machine power consumption	＜250W
Whole machine operating temperature	0-40℃
